VD-800/800Q Fully Automatic Toilet Sewage Pump

The VD-800/800Q Fully Automatic Toilet Sewage Pump is an innovative solution that eliminates the need for extensive remodeling when adding a new bathroom. Its compact size and aesthetic design make it an attractive and practical choice for any installation.

Installation is straightforward—simply connect the waste outlet from the sanitary fixtures to the pump unit. Once the wastewater accumulates to the pre-set level, the pump automatically activates, using its powerful motor to transport the waste to the main sewage line. This automatic operation ensures that wastewater is efficiently removed without requiring manual intervention.

The smart control panel enhances safety by monitoring the pump's performance in real time. It provides comprehensive protection through automatic sewage discharge, intelligent motor reversal, and real-time fault alerts. Users can easily switch between three operational modes—Silent, Energy-Saving, and Powerful—by pressing a single button, making it adaptable to various needs.

Key Features

Blockage Prevention
High-Performance Blades: Equipped with U58HRC 440 stainless steel grinding blades, the VD-800/800Q ensures that even the waste materials are efficiently cut and processed. This high-hardness stainless steel is known for its durability and resistance to wear, ensuring long-term performance.
Large Flow Passage: The pump features a large channel flow design that reduces the risk of blockages and clogs. This design allows for smooth and uninterrupted sewage flow, even with larger waste particles.
Permanent Magnet Motor: The pump utilizes a powerful permanent magnet motor that provides robust cutting power. The motor’s intelligent control ensures good performance and efficiency.

Ultra-High Performance
IE5 High-Performance Motor: The VD-800/800Q is powered by an IE5 high-performance permanent magnet motor, which is known for its energy efficiency and performance. This motor can achieve a head of up to 17 meters, making it suitable for a wide range of applications.
Impressive Flow Rate: With a flow rate of 9 cubic meters per hour, this pump significantly surpasses the performance of many competing products. This high flow rate ensures that large volumes of wastewater are handled quickly and efficiently.

Convenient Operation
Three-Mode Operation: The VD-800/800Q offers three operational modes—Silent, Energy-Saving, and Powerful—each selectable with a single button. This versatility allows users to choose the mode that suits their needs, whether it's for quiet operation, energy efficiency, or power.
Fault Alerts and Display: The pump is equipped with a large display screen that provides real-time information and fault alerts. This feature ensures that users are immediately informed of any issues, allowing for quick resolution and less downtime.

Safety and Reliability
IP65 Protection Rating: With an IP65 protection rating, the VD-800/800Q is designed to be resistant to water ingress. This ensures reliable operation even in wet environments, offering peace of mind and durability.
Activated Carbon Filter: To eliminate unpleasant odors, the pump features an exhaust valve with a replaceable activated carbon filter. This helps maintain a fresh and odor-free environment.

Ease of Installation
Convenient Accessories: The VD-800/800Q comes with free soft hose adapters for both inlet and outlet connections, simplifying the installation process. These adapters ensure a secure and leak-free connection to the plumbing system.
Flexible Installation Options: The pump is designed for versatile installation, allowing for both rear and side discharge. This flexibility accommodates various setup configurations and space constraints.
